Product type and advantage
Lithium iron phosphate material has extremely stable performance as a core materia
Part No | Nominal
Voltage | Rated
Capacity | Internal
Resistance | Discharge
Rate | Dimension(mm) | Weight(g) |
Diameter | Height |
WBCF18650-1100-3.2V | 3.2V | 1100mAh | ＜15 m Ω | 30C | 18.1±0.1 | 65.2±0.1 | 43 |
WBCF18650-1500-3.2V | 3.2V | 1500mAh | ＜28 m Ω | 3C | 18.1±0.1 | 65.2±0.1 | 43 |
WBCF18650-1600-3.2V | 3.2V | 1600mAh | ＜28 m Ω | 3C | 18.1±0.1 | 65.2±0.1 | 43 |
WBCF18650-1800-3.2V | 3.2V | 1800mAh | ＜40 m Ω | 3C | 18.1±0.1 | 65.2±0.1 | 45 |
WBCF18650-2000-3.2V | 3.2V | 2000mAh | ＜40 m Ω | 1C | 18.1±0.1 | 65.2±0.1 | 46 |
WBCF26650-2500-3.2V | 3.2V | 2500mAh | ＜15 m Ω | 20C | 26.5±0.1 | 65.2±0.2 | 87 |
WBCF26650-3000-3.2V | 3.2V | 3000mAh | ＜15 m Ω | 10C | 26.5±0.1 | 65.2±0.2 | 85 |
WBCF26650-3200-3.2V | 3.2V | 3200mAh | ＜25 m Ω | 3C | 26.5±0.1 | 65.2±0.2 | 85 |
WBCF26650-3300-3.2V | 3.2V | 3300mAh | ＜25 m Ω | 3C | 26.5±0.1 | 65.2±0.2 | 85 |
WBCF26650-3400-3.2V | 3.2V | 3400mAh | ＜25 m Ω | 3C | 26.5±0.1 | 65.2±0.2 | 85 |
WBCF26650-3600-3.2V | 3.2V | 3600mAh | ＜25 m Ω | 3C | 26.5±0.1 | 65.2±0.2 | 85 |
WBCF26650-3800-3.2V | 3.2V | 3800mAh | ＜25 m Ω | 3C | 26.5±0.1 | 65.2±0.2 | 87 |
WBCF26650-4000-3.2V | 3.2V | 4000mAh | ＜25 m Ω | 1C | 26.5±0.1 | 65.2±0.2 | 88 |
WBCF32650-5500-3.2V | 3.2V | 5500mAh | ＜15 m Ω | 3C | 32.2±0.1 | 65.8±0.2 | 145 |
WBCF32700-6000-3.2V | 3.2V | 6000mAh | ＜15 m Ω | 3C | 32.2±0.1 | 70.5±0.2 | 155 |
