Ternary product types and advantages
The ternary material as a core material greatly enhances the energy density of the product up to 240Wh/kg.
Part No | Nominal
Voltage | Rated
Capacity | Internal
Resistance | Discharge
Rate | Dimension(mm) | Weight(g) |
Diameter | Height |
WBCNR18650-1500-3.6V | 3.6V | 1500mAh | ＜20 m Ω | 15C | 18.1±0.1 | 65.2±0.1 | 45 |
WBCNR18650-2000-3.6V | 3.6V | 2000mAh | ＜30 m Ω | 3C | 18.1±0.1 | 65.2±0.1 | 44 |
WBCNR18650-2200-3.6V | 3.6V | 2200mAh | ＜40 m Ω | 3C | 18.1±0.1 | 65.2±0.1 | 45 |
WBCNR18650-2600-3.6V | 3.6V | 2600mAh | ＜40 m Ω | 3C | 18.1±0.1 | 65.2±0.1 | 47 |
WBCNR18650-3000-3.6V | 3.6V | 3000mAh | ＜40 m Ω | 3C | 18.1±0.1 | 65.2±0.1 | 48 |
WBCNR21700-3000-3.2V | 3.6V | 3000mAh | ＜20 m Ω | 3C | 21.8±0.1 | 70.1±0.3 | 68 |
WBCNR21700-4000-3.6V | 3.6V | 4000mAh | ＜60 m Ω | 3C | 21.8±0.1 | 70.1±0.3 | 69 |
WBCNR26650-4500-3.6V | 3.6V | 4500mAh | ＜30 m Ω | 3C | 26.5±0.1 | 65.2±0.1 | 87 |
WBCNR26650-5000-3.6V | 3.6V | 5000mAh | ＜30 m Ω | 3C | 26.5±0.1 | 65.2±0.1 | 88 |
